UNX6010-B
Standard high speed bulk material X-Ray foreign contamination detection equipment
Online
Hotline
400-880-1456
Product features
Multi-modal large model Al artificial intelligence algorithm
Multi-modal foreign object pairing recognition
quick one-click operation
Food grade material &IP6 waterproof rating
Powerful and robust data analysis capabilities
High resolution, high speed, high detection accuracy
Technical Parameter
Dimension | 2480mm(L)×1300mm(W)×2070mm(H) | Weight | 750kg |
| X-ray source | 80KV | Power supply | AC220V,1.5KVA,50/60Hz |
| Detector | 0.2mm/0.4mm/TDI | Maximum load | 10KG |
| Channel size | W*H =60*10cm | Form of the detected item | bulk |
| Conveyor speed | 10-120M/min | ||
| Protection level | Product channel IP66, other IP65 | Safety | ≦1uSv/h |
| External interfaces included | 1*LAN，2*USB | Conveyor belt material | Food grade PU |
| Display language | Chinese, English and other languages are available | ||
| Operating environment | Relative temperature -10~40 ℃, relative humidity 30-90%, no condensation | ||
| Human-computer interface | 17.3-inch LCD touch screen, Windows 10 system | ||
Applications
-
Cold chain fruits and vegetables -
Roasted nuts -
Grains and miscellaneous grains -
Condiments
